Engine D4HB HYUNDAI KIA SANTA FÉ II 2 CARNIVAL GRAND III 3 SUV SORENTO GRANDEUR FE IV 4 STARIA 2.2 CRDi 4x4 4WD D Allwheel Drive AWD 197hp 150hp 194hp 200hp 177hp

Engine D4HB HYUNDAI KIA SANTA FÉ II 2 CARNIVAL GRAND III 3 SUV SORENTO GRANDEUR FE IV 4 STARIA 2.2 CRDi 4x4 4WD D Allwheel Drive AWD 197hp 150hp 194hp 200hp 177hp

Buy D4HB engine

from

3.149,00

🟡 Occasionally in stock

⚠️ Note on availability:

Due to high demand and rapidly changing stock levels, we are unable to display real-time availability in our webshop. The availability indication therefore represents an estimate of the likelihood that a motor is currently in stock.

For binding information and a concrete offer, we kindly ask you to submit a request. You will receive an offer within a few hours.

incl. VAT, plus shipping costs

4–8 business days delivery time.

In Stock

Online orders in our online shop is currently not available: please fill out the “Availability Request Form” first. You will then receive a tailored offer in PDF format, after which you can place your order directly via email or phone.

Non-committal offer: This engine (D4HB) is also available through other sales channels (both online and offline). Consequently, the possibility of a short-term intermediate sale cannot be ruled out. It is essential to check the engine’s availability and compatibility with your vehicle before proceeding.

WE ARE HERE TO HELP YOU!

Available D4HB engines

Discover our diverse range of engines – perfectly tailored to your individual needs. Whether you're looking for affordable replacement engines, complete engines, or professional engine overhauls: with us, you're guaranteed to find the right solution for your vehicle.


The listed prices vary depending on the mileage and current stock levels/capacities. You will receive a binding price with a customized offer upon request.

Our used D4HB engine without attachments includes the following scope of delivery:

  • Tested short block (engine block with oil pump, crankshaft, bearings, connecting rods, pistons)

  • Cylinder head including camshaft and valves

  • Oil pan & valve cover (used as transport protection, may need to be reused from the old part)

  • Testing procedures: Leak-down test, cylinder inspection with endoscope camera, inspection of oil pan and valve cover, visual check of crankshaft & camshafts, examination of residues in oil pump and oil pan

The timing chain/belt must be replaced before installation.
Request the availability of the engine now—free and without obligation:

Our complete used D4HB engine with attachments includes the following scope of delivery:

  • Tested engine (engine block + cylinder head)

  • Untested attachments such as starter, injectors, injection system, turbocharger, ignition coils, intake manifold, and much more

  • Oil pan & valve cover used as transport protection (may need to be reused from the old part)

  • Testing procedures: Leak-down test, cylinder inspection with endoscope camera, inspection of oil pan and valve cover, examination of residues in oil pump and oil pan

Attachments are included free of charge, but without any warranty.
The timing chain/belt must always be replaced before installation.
Request the availability of the engine now—free and without obligation:

Our overhauled D4HB engine without attachments has been fully reconditioned to 0 km and includes:

  • Fully overhauled engine block with cylinder head

  • New parts: valves, valve stem seals, piston rings, main/connecting rod bearings, oil pump, internal timing chain/belt

  • Processing & testing procedures: camshaft and crankshaft are measured, polished, crack-tested, and ultrasonically cleaned; cylinder head is measured, resurfaced, and ultrasonically cleaned; block is honed, ground, and measured; pistons are inspected, cleaned, and undergo UV crack testing

A durable engine in like-new condition – ideal for the highest demands.
Request the availability of the engine now—free and without obligation.

With our customer engine overhaul service, we recondition your defective D4HB engine:

  • Collection of your engine (without attachments)

  • Professional overhaul to 0 km with high-quality new parts (e.g., Kolbenschmidt, FEBI, FAI)

  • New parts: valves, piston rings, oil pump, bearings, internal timing chain/belt

  • Processing & testing procedures: camshaft and crankshaft are measured, polished, crack-tested, and ultrasonically cleaned; cylinder head is measured, resurfaced, and ultrasonically cleaned; block is honed, ground, and measured; pistons are inspected, cleaned, and undergo UV crack testing

After approximately 10–12 business days, you will receive your reconditioned engine back.
Request the availability of the overhaul service now—free and without obligation.

Check compatibility and availability of engine D4HB

Kindly complete the “request for quote” form. We will confirm whether the engine D4HB matches your vehicle and provide you with detailed proposals for all the available options, whether you’re looking for a used engine, a reconditioned one, or prefer it bare or complete. Following this, you may proceed to place your order directly.

Engine description:

Your benefits:

Compatible vehicles with engine D4HB:

D4HB Engine Technical Specifications & Compatibility.

Additional information

Engine Code

D4HB

Make

HYUNDAI, KIA

Model

CARNIVAL GRAND CARNIVAL III VQ, GRAND SANTA FÉ, GRANDEUR HG, SANTA FÉ II CM, SANTA FÉ II SUV CM, SANTA FÉ III DM DMA, SANTA FÉ III SUV DM, SANTA FE IV SUV TM, SANTA FE IV TM TMA, SORENTO II SUV XM, SORENTO II XM, SORENTO III UM, STARIA US4

Motorization

2.2 CRDi, 2.2 CRDi 4WD, 2.2 CRDi 4×4, 2.2 CRDi Allwheel Drive, 2.2 CRDi AWD, 2.2 D, CRDi, CRDi 4WD, CRDi 4×4

Power (hp)

150hp, 177hp, 194hp, 197hp, 200hp

Power (kW)

110kW, 130kW, 143kW, 145kW, 147kW

Fuel

Diesel

Number of Cylinders

4

Engine Capacity (ccm)

2199

Torque (Nm)

412

Compression

17.3

Bore (mm)

85.4

Stroke (mm)

96

Number of Bearings

5

Number of Valves

16

Engine Charging

Exhaust Turbocharger

Combustion

Diesel

Fuel Mixture

Direct Injection

Engine Type

Straight

Cylinder Type

DOHC

Engine Management

Chain

Price Used Engine (€)

3149

Price Complete Engine (€)

3949

Price Engine Overhaul (€)

3949

About Us

Robust and durable D4HB engine for HYUNDAI, KIA

Thoroughly tested HYUNDAI, KIA D4HB engine

Our service for the D4HB engine

Awards and Reviews for Fair-Motors

Award for being the most popular engine dealer in Germany
"FAIR-MOTORS is the MOST POPULAR engine dealer on the biggest comparison platform for engines and engine repair (MotorschadenVergleich.de)."
Rated 4.68 out of 5
Excellent
4,68 out of 5,00 Stars
total 327 Reviews
89,76% positive
(Sep. 2022)

Information about the HYUNDAI, KIA replacement engine D4HB:

The D4HB engine is used by the manufacturer HYUNDAI, KIA in the following models: CARNIVAL GRAND III 3, GRAND SANTA FÉ, GRANDEUR, SANTA FÉ II 2, SANTA FÉ II 2 SUV, SANTA FÉ III 3, SANTA FÉ III 3 SUV, SANTA FE IV 4, SANTA FE IV 4 SUV, SORENTO II 2, SORENTO II 2 SUV, SORENTO III 3, STARIA.

Engine type and performance:

Depending on the engine control unit, the Diesel engine D4HB has an output of 150hp, 177hp, 194hp, 197hp, 200hp, which is equivalent to 110kW, 130kW, 143kW, 145kW, 147kW.

The 4-cylinder Exhaust Turbocharger engine is Water-cooled and produces a torque of 412Nm with a displacement of 2199ccm.

The 2.2 CRDi, 2.2 CRDi 4WD, 2.2 CRDi 4×4, 2.2 CRDi Allwheel Drive, 2.2 CRDi AWD, 2.2 D, CRDi, CRDi 4WD, CRDi 4×4 D4HB engine features 16 valves, 5 bearings, and achieves a compression ratio of 17.3 with a stroke of 96 mm and a bore of 85.4 mm.

It is a DOHC Diesel Straight engine with Direct Injection, powered by a Chain.

Detailed list of compatible vehicles for the engine D4HB:

Make Model Motorization
HYUNDAIGRAND SANTA FÉ [from 2013/01]2.2 CRDi All-wheel Drive [193 hp, 142 kW, 2199 cc, from 2017/06]
HYUNDAIGRAND SANTA FÉ [from 2013/01]2.2 CRDi All-wheel Drive [197 hp, 145 kW, 2199 cc, from 2013/06]
HYUNDAIGRAND SANTA FÉ [from 2013/01]2.2 CRDi All-wheel Drive [200 hp, 147 kW, 2199 cc, from 2013/09]
HYUNDAIGRAND SANTA FÉ [from 2013/01]2.2 CRDi All-wheel Drive [203 hp, 149 kW, 2199 cc, from 2015/06]
HYUNDAIGRAND SANTA FÉ [from 2013/01]2.2 CRDi All-wheel Drive [260 hp, 191 kW, 2199 cc, from 2014/01]
HYUNDAIGRAND SANTA FÉ [from 2013/01]2.2 CRDi [200 hp, 147 kW, 2199 cc, from 2013/09]
HYUNDAIGRAND SANTA FÉ [from 2013/01]2.2 CRDi [203 hp, 149 kW, 2199 cc, from 2015/06]
HYUNDAIGRANDEUR (HG) [from 2011/01]2.2 D [200 hp, 147 kW, 2199 cc, from 2011/01]
HYUNDAIGRANDEUR (HG) [from 2011/01]2.2 D [203 hp, 149 kW, 2199 cc, from 2014/09 to 2016/10]
HYUNDAIGRANDEUR (IG) [from 2016/11]2.2 CRDI [203 hp, 149 kW, 2199 cc, from 2016/11]
HYUNDAIPALISADE (LX2) [from 2018/12]2.2 2.2 CRDI [200 hp, 147 kW, 2199 cc, from 2021/01]
HYUNDAIPALISADE (LX2) [from 2018/12]2.2 8AT4 [193 hp, 142 kW, 2199 cc, from 2021/08]
HYUNDAIPALISADE (LX2) [from 2018/12]2.2 CRDI E-VGT HTRAC [203 hp, 149 kW, 2199 cc, from 2018/12]
HYUNDAIPALISADE (LX2) [from 2018/12]2.2 CRDI E-VGT [203 hp, 149 kW, 2199 cc, from 2018/12]
HYUNDAIPALISADE (LX2) [from 2018/12]2.2 CRDI HTRAC [200 hp, 147 kW, 2199 cc, from 2021/01]
HYUNDAISANTA FÉ II (CM) [from 2005/01 to 2015/03]2.2 CRDi 4x4 [197 hp, 145 kW, 2199 cc, from 2009/01 to 2012/12]
HYUNDAISANTA FÉ II (CM) [from 2005/01 to 2015/03]2.2 CRDi 4x4 [200 hp, 147 kW, 2199 cc, from 2009/01 to 2012/12]
HYUNDAISANTA FÉ II (CM) [from 2005/01 to 2015/03]2.2 CRDi [197 hp, 145 kW, 2199 cc, from 2009/01 to 2012/12]
HYUNDAISANTA FÉ II (CM) [from 2005/01 to 2015/03]2.2 CRDi [200 hp, 147 kW, 2199 cc, from 2009/01 to 2010/12]
HYUNDAISANTA FÉ II SUV Van (CM) [from 2005/10 to 2015/03]CRDi 4x4 [197 hp, 145 kW, 2199 cc, from 2009/01 to 2013/05]
HYUNDAISANTA FÉ II SUV Van (CM) [from 2005/10 to 2015/03]CRDi [197 hp, 145 kW, 2199 cc, from 2009/01 to 2013/05]
HYUNDAISANTA FÉ III (DM, DMA) [from 2012/09]2.2 CRDi 4WD [197 hp, 145 kW, 2199 cc, from 2012/09 to 2015/12]
HYUNDAISANTA FÉ III (DM, DMA) [from 2012/09]2.2 CRDi 4WD [200 hp, 147 kW, 2199 cc, from 2015/10]
HYUNDAISANTA FÉ III (DM, DMA) [from 2012/09]2.2 CRDi 4WD [202 hp, 149 kW, 2199 cc, from 2015/06]
HYUNDAISANTA FÉ III (DM, DMA) [from 2012/09]2.2 CRDi AWD [193 hp, 142 kW, 2199 cc, from 2018/07]
HYUNDAISANTA FÉ III (DM, DMA) [from 2012/09]2.2 CRDi [193 hp, 142 kW, 2199 cc, from 2018/07]
HYUNDAISANTA FÉ III (DM, DMA) [from 2012/09]2.2 CRDi [197 hp, 145 kW, 2199 cc, from 2012/09 to 2015/12]
HYUNDAISANTA FÉ III (DM, DMA) [from 2012/09]2.2 CRDi [200 hp, 147 kW, 2199 cc, from 2015/10]
HYUNDAISANTA FÉ III (DM, DMA) [from 2012/09]2.2 CRDi [202 hp, 149 kW, 2199 cc, from 2015/06]
HYUNDAISANTA FÉ III SUV Van (DM) [from 2012/09]CRDi 4x4 [197 hp, 145 kW, 2199 cc, from 2015/05]
HYUNDAISANTA FE IV (TM, TMA) [from 2018/02]2.2 CRDi AWD [193 hp, 142 kW, 2199 cc, from 2018/07]
HYUNDAISANTA FE IV (TM, TMA) [from 2018/02]2.2 CRDi AWD [200 hp, 147 kW, 2199 cc, from 2018/07]
HYUNDAISANTA FE IV (TM, TMA) [from 2018/02]2.2 CRDi AWD [203 hp, 149 kW, 2199 cc, from 2018/02]
HYUNDAISANTA FE IV (TM, TMA) [from 2018/02]2.2 CRDi [193 hp, 142 kW, 2199 cc, from 2018/07]
HYUNDAISANTA FE IV (TM, TMA) [from 2018/02]2.2 CRDi [200 hp, 147 kW, 2199 cc, from 2018/07]
HYUNDAISANTA FE IV (TM, TMA) [from 2018/02]2.2 CRDi [203 hp, 149 kW, 2199 cc, from 2018/02]
HYUNDAISANTA FE IV SUV Van (TM) [from 2018/02]2.2 CRDi AWD [200 hp, 147 kW, 2199 cc, from 2018/07]
HYUNDAISANTA FE IV SUV Van (TM) [from 2018/02]2.2 CRDi [200 hp, 147 kW, 2199 cc, from 2018/07]
HYUNDAISTARIA Bus (US4) [from 2021/01]2.2 CRDi (US4W) [177 hp, 130 kW, 2199 cc, from 2021/01]
HYUNDAISTARIA Bus (US4) [from 2021/01]2.2 CRDi AWD (US4W) [177 hp, 130 kW, 2199 cc, from 2021/01]
HYUNDAISTARIA Van (US4) [from 2021/01]2.2 CRDi (US4V) [177 hp, 130 kW, 2199 cc, from 2021/01]
KIACADENZA II (YG) [from 2016/01]2.2 CRDi [203 hp, 149 kW, 2199 cc, from 2016/01]
KIACARNIVAL / GRAND CARNIVAL III (VQ) [from 2005/09]2.2 CRDi [150 hp, 110 kW, 2199 cc, from 2010/01]
KIACARNIVAL / GRAND CARNIVAL III (VQ) [from 2005/09]2.2 CRDi [192 hp, 141 kW, 2199 cc, from 2010/01 to 2015/06]
KIACARNIVAL / GRAND CARNIVAL III (VQ) [from 2005/09]2.2 CRDi [194 hp, 143 kW, 2199 cc, from 2010/01]
KIACARNIVAL / GRAND CARNIVAL III (VQ) [from 2005/09]2.2 CRDi [197 hp, 145 kW, 2199 cc, from 2010/01 to 2015/06]
KIACARNIVAL IV (KA4) [from 2020/09]2.2 [202 hp, 149 kW, 2199 cc, from 2020/09]
KIASEDONA III (YP) [from 2014/09]2.2 CRDi [190 hp, 140 kW, 2199 cc, from 2015/07]
KIASEDONA III (YP) [from 2014/09]2.2 CRDI [197 hp, 145 kW, 2199 cc, from 2015/07]
KIASEDONA III (YP) [from 2014/09]2.2 CRDI [203 hp, 149 kW, 2199 cc, from 2015/07]
KIASEDONA III (YP) [from 2014/09]2.2 TD [200 hp, 147 kW, 2199 cc, from 2015/07]
KIASORENTO II (XM) [from 2009/09 to 2016/04]2.2 CRDi 4WD [197 hp, 145 kW, 2199 cc, from 2009/11 to 2015/12]
KIASORENTO II (XM) [from 2009/09 to 2016/04]2.2 CRDi 4WD [200 hp, 147 kW, 2199 cc, from 2009/11 to 2015/12]
KIASORENTO II (XM) [from 2009/09 to 2016/04]2.2 CRDi [197 hp, 145 kW, 2199 cc, from 2009/11 to 2015/12]
KIASORENTO II (XM) [from 2009/09 to 2016/04]2.2 CRDi [200 hp, 147 kW, 2199 cc, from 2009/11 to 2015/12]
KIASORENTO II SUV Van (XM) [from 2009/06 to 2015/12]CRDi 4WD [197 hp, 145 kW, 2199 cc, from 2009/11 to 2015/12]
KIASORENTO II SUV Van (XM) [from 2009/06 to 2015/12]CRDi [197 hp, 145 kW, 2199 cc, from 2009/11 to 2015/12]
KIASORENTO III (UM) [from 2015/01]2.2 CRDI 4WD [193 hp, 142 kW, 2199 cc, from 2016/11]
KIASORENTO III (UM) [from 2015/01]2.2 CRDI 4WD [197 hp, 145 kW, 2199 cc, from 2016/11]
KIASORENTO III (UM) [from 2015/01]2.2 CRDi 4WD [200 hp, 147 kW, 2199 cc, from 2015/01]
KIASORENTO III (UM) [from 2015/01]2.2 CRDi 4WD [202 hp, 149 kW, 2199 cc, from 2015/01]
KIASORENTO III (UM) [from 2015/01]2.2 CRDi [194 hp, 143 kW, 2199 cc, from 2015/01]
KIASORENTO III (UM) [from 2015/01]2.2 CRDi [200 hp, 147 kW, 2199 cc, from 2015/01]
KIASORENTO III (UM) [from 2015/01]2.2 CRDi [202 hp, 149 kW, 2199 cc, from 2015/01]

FAQ:

The quickest way is to fill out the “request for quote” form. Please provide the engine code D4HB and your VIN number so we can accurately identify the engine that is compatible with your vehicle. You will swiftly receive a detailed offer in PDF format via email. If everything matches, you can then proceed with the order.

It depends on the inventory. We sell D4HB engines either complete or bare. The complete engines come with spare parts included.

The engine is compatible with the following make and models:
HYUNDAI, KIA | CARNIVAL GRAND III 3, GRAND SANTA FÉ, GRANDEUR, SANTA FÉ II 2, SANTA FÉ II 2 SUV, SANTA FÉ III 3, SANTA FÉ III 3 SUV, SANTA FE IV 4, SANTA FE IV 4 SUV, SORENTO II 2, SORENTO II 2 SUV, SORENTO III 3, STARIA

To be certain, you should provide us with your VIN number so we can verify the engine’s compatibility.

The contents of the delivery vary depending on the engine. For the complete engine, we deliver the engine block with the cylinder head, valve cover, oil pan, and the injection system, turbocharger, alternator, manifold, wiring harness, etc. For the bare engine without ancillary parts, we deliver the engine block with the cylinder head, valve cap, and oil pan.

  • The contents of the delivery may vary. Please check the exact contents of the delivery in the PDF offer.

The mileage depends on the condition of the engine. The overhauled engine has been reset to 0km. The mileage of the used engine can vary. Make a brief inquiry on our website, and you will receive a detailed offer with precise mileage information.

The following parts are replaced with NEW ones:

  • Valves
  • Valve stem seals
  • Piston rings
  • Connecting rod bearings and main bearings
  • Oil pump
  • Timing chain with tensioner

Additional revision steps:

  • The camshaft and crankshaft are measured, polished, checked for cracks, and ultrasonically cleaned.
  • The cylinder head is measured, leveled, and ultrasonically cleaned.
  • The block is planed, sanded, and measured.
  • Pistons are inspected, cleaned, and subjected to UV crack testing.
  • Leakdown tests

✅ We can, of course, also overhaul your faulty engine.

FULL SERVICE:

We handle everything in-house, from engine overhauling to marketing and web design. This cuts down on many costs.

EFFICIENT USE OF OUR MACHINES:

Our processes are finely tuned, ensuring no downtime. Our machines and staff are fully utilized.

OPTIMIZED TASK DISTRIBUTION:

Each person works solely within their area of expertise. For instance, we have different specialists for various makes/types of engines. This saves a significant amount of time and enhances quality.

Yes, sometimes. The deposit varies depending on the engine.

The price of the engine varies depending on the engine’s condition:

Used engine: 3149 €

Complete engine: 3949 €

Overhauled engine: €

Engine Overhaul: 3949 €

Please note: Prices and availability are provided for guidance only!

Make an inquiry on the website to receive a detailed and final offer.
